Product Specification
| Printer Specifications | |
| Resolution | 203DPI |
|
Print Method |
Direct Thermal |
| Memory | 8 MB RAM / 8 MB Flash |
| Max.Print Width | 4.25 in. / 108 mm |
| Max.Print Speed | Up to 8 ips (203 mm/s) |
| Media Sensors | Movable Black Mark Sensor / Movable Gap Sensor |
| Emulation | TSPL, ZPL, EPL, DPL |
| Interface | USB+Serial, USB+Lan, USB+Serial+Lan (Optional Wireless Connectivity: Bluetooth / Wi-Fi) |
| Others | Optional RTC, Standard SD Card Slot |
| Display Screen | 1.54" OLED, 128×64 Pixel |
|
Media and Ribbon Characteristics |
|
|
Media Length |
0.39 in.~70 in.(10 mm ~ 1778 mm) |
|
Media Width |
1.56 in. - 4.7 in. (40 mm - 120 mm) |
|
Media Thickness |
0.0023 in.(0.06 mm) Min.;0.01 in.(0.254 mm) Max. |
|
Media Types |
Continuous, Gap, Black mark, Fan-fold, Perforated Media |
|
Environment Condition |
|
|
Operating Temp. |
5~40℃(41~104℉) |
|
Storage Temp. |
-40~60℃(-40~140℉) |
|
Operating Humidity |
25 ~ 85% Non-Condensing |
|
Storage Humidity |
10 ~ 90% Non-Condensing |
|
Fonts/Graphics/Symbologies |
|
|
1D Bar Codes |
Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar,Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E,EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 |
|
2D Bar Codes |
PDF-417, Maxicode, DataMatrix, QR code, Aztec |
|
Fonts and Graphics |
Font 0 ~ Font 8 |
|
Software |
|
|
Driver |
Windows / Linux / Mac / Android / Chrome OS |
|
SDK |
Windows / Linux / Android / iOS |
|
Software |
Bartender UltraLite / Mobile Label Design App |
|
Accessories |
|
|
Standard Accessories |
Power Adapter ×1, Power Cord ×1, USB Cable ×1, User Manual ×1, CD ×1 |
|
Factory Installed Options |
Bluetooth Module, Wi-Fi Module |
|
User Options |
8" External Paper Roll Holder |
|
Product Warranty |
|
|
Printhead life |
The earlier of 30 km usage or 1 year |
|
Platen roller life |
The earlier of 30 km usage or 1 year |
|
Printer Warranty |
1 Year |
|
Physical Characteristics |
|
|
Dimension |
220 mm × 187 mm × 96 mm (D × W × H) |
|
Weight |
3.15 Kg |
